Minimum Order Quantity :	1pieces	Price :	USD 200~349 stes
Packaging Details :	20cm12cm6cm	Delivery Time :	5-7days
Payment Terms :	T/T, L/C	Supply Ability :	2000 stes month

Place of Origin:	CHINA	Brand Name:	Mobydata
Certification:	CE,FCC,RoHS	Model Number:	M71S

Detail Information
Products:	Rugged Handheld Devices	Operating System:	Quad /Octa Core, 2GHz, 12nm, Android 9
Memory:	2+16/3+32	Battery:	4000mAH
Dimension:	160mmx71mmxl 7 Mm	Keypad:	24 Numeric Keypad
IP:	IP65	Scan Engine:	Mobydata E3200/E3250 Increased 45 Degree Sc
LCD:	4.0 Inch, 800*480, Visible Under Sunshine
Highlight:	Rugged Handheld Computer Device , Customized Handheld Computer Device , Rugged Handheld Devices

M71 Specifications
OS	Android 9
CPU	2GHz, Quad/Octa Core, 12nm
MEMORY	2+16/3+32
Extend Slot	MicroSD, support SDHC, up to 64GB;
Extend Slot	One micro SIM connector
PC Communication	USB 2.0 OTG : Type-C；Support TYPE-C Headset
Sensers	Light, Proximity, 3D G sensor, Hall
LED	Charging, Scan and System stauts
Charging Time	<3.5 hours(Room Temperature)
Charging Time	<4 hours(35 ℃)
Operation Duration	14 hours
Data Collection
Scan Engine	Mobydata E3200-LE/E3250-LE
2D	Aztec Code; China Han Xin Code; Data Matrix; MaxiCode;
	Micro QR Code; QR Code; EAN/JAN Composites; GS1 DataBar Composites;
	GS1 DataBar Expanded Stacked; GS1 DataBar Stacked;
	GS1 DataBar Stacked Omnidirectional; MacroPDF;
	MicroPDF417; PDF417; UPC A/E Composites
1D	Auto discriminates all standard 1D codes including GS1
1D	DataBar™ linear codes.
Post	Australian Post; British Post; China Post; IMB; Japanese
	Post; KIX Post; Korea Post; Planet Code; Postnet; Royal
	Mail Code (RM4SCC)
NFC(Optional)	13.56MHz NFC
Wireless Connectivity
WLAN	802.11 ac/a/b/g/n
WWAN	TDD-LTE (B38/B39/B40/B41)
	FDD-LTE (B1/B3/B7)
	UMTS/HSDPA/HSPA/HSPA+ (900/2100 MHz)
	GSM/EDGE/GPRS (900/1800MHz)
VoLTE	LTE CAT6
CA	Downlink 300Mbps, B1/B3/B7/B40/B41
WPAN	BT 4.2/BLE
GPS	GPS/A-GPS, GLONASS, Beidou ,Galileo
Physical Specifications
LCD	4 inch, 800*480, visible under sunshine
Touch	GFF Captive Touch, Dragontrail Glass
Camera	Auto focus 8Mega, with flash LED
Keypad	24 Numeric Keypad
	Left/Right Scan Key, Left/Right K1,K2 user-defined Key
	Back, HOME, Switch
Reciver	Support
Speaker	Min 90db at 10cm-1KHz Voice
Mic	Noise Reduction Mic
Charging IO	USB type-C,
Charging IO	Charging Pad
Battery	Removable 3800mAh-4000mAh
Dimension	160×71×17mm
Weight	269g
Environmental Specifications
Operation Temperature	-20°C ~ +50°C
Storage Temperature	-30°C ~ +70°C
Humidity	10% ~ 90%
Drop	1.5m, concrete, 12 drops
Tumble	600hits, 0.5m, Steel
IP	IP65
ESD	±8kV Contact, ±15kV Air
Keypad lifecycle	300K
Accessories
Charging Cradle	Support 1 device and 1 battery
Handstrap	Black, Nylon
Battery	Removable 3800mAh-4000mAh
Gift Box
Device, Battery, QSG, Adapter, USB cable.

Customized Rugged Handheld Computer Devices for Data Collection

Rugged Handheld Computer Device

Customized Handheld Computer Device

Rugged Handheld Devices
